Imation Solid State Drives

What is SSD?

• A solid state drive (SSD) is an advanced data storage device that uses NAND flash memory or in some cases SDRAM to store continuous data.
• An SSD emulates a conventional hard disk drive (HDD), easily substituting it in most applications.
• SSDs may contain either single-level cell (SLC) or multi-level cell (MLC) NAND flash memory providing significant differences in read/write performance and endurance.
• Without motors or moving parts, Imation Solid State Drives powered by Mtron utilize industry-leading controller technology to provide faster and more reliable data storage than traditional hard disk drives (HDDs), and also offer lower heat and noise generation while providing greatly improved durability and shock resistance.

Why SSD?

• Compared to a HDD, an Imation SSD powered by Mtron can accelerate performance of high availability applications and significantly reduce total cost of ownership because they are:

  • Faster. With reads speeds up to 120 MB per second and write speeds up to 90 MB per second, Imation SSDs powered by Mtron drastically improve HDD performance.
  • Longer lasting. An intelligent algorithm ensures advanced wear-leveling and even usage of the entire flash memory region.
  • More reliable. An Imation SSD powered by Mtron has a mean time between failures (MTBF) of one million hours. Plus, it provides enhanced data integrity due to its 7-bit error correction code (ECC) and advanced bad block management.
  • More robust. With no moving parts, an SSD is more tolerant of extreme shocks, vibrations and temperatures.
  • More power efficient. Due to its solid state, an SSD uses less power and therefore emits less heat, reducing data center management costs.
  • Noiseless. Reduces ambient noise in data centers and offices.

Solid State Drive		Hard Disk Drive
No moving parts - solid state construction		Moving parts - rotating platter with mechanical arm
Tolerant of shock and vibration		Susceptible to damage from shock and vibration
Higher cost per GB		Lower cost per GB
Very fast random access and read speeds		Slower read/write performance
Ideal for lower capacity: 16GB to 128GB		Higher total capacity, up to 1TB
Lower power consumption		Higher power consumption

Solid State  Drives		MOBI 3000 Series		PRO 7000 Series
Function		Data and application storage		Accelerator and data storage
Key features		High-performance data storage, temperature and shock-resistant, rugged and lightweight, reduced power consumption for enhanced battery life		High performance data storage, extremely fast response times, enhanced reliability, reduced power consumption, low heat and noise generation
Target users		Performance-oriented power users who demand instant access to their critical data		IT and data center managers looking for high-performance back office solutions
Key applications		Drive-intensive applications such as graphics and design		Extreme performance data center applications such as storage arrays, database servers, Web servers and other network appliances
Capacities		2.5" - 16GB, 32GB, 64GB 3.5" - 16GB, 32GB, 64GB, 128GB		2.5" - 16GB, 32GB, 64GB 3.5" - 16GB, 32GB, 64GB, 128GB
Cases		White/Plastic		Silver/Aluminum
Average Access Time		0.1 msec		0.1 msec
Sustained Read		100MB/sec*+		120MB/sec*+
Sustained Write		80MB/sec*+		90MB/sec*+
Input Output operations per Second (Sequential/Random)		78,000/16,000**+		81,000/18,000**+
Input Voltage		5VCC+/-5%		5VCC+/-5%
Write Endurance		Intelligent algorithm ensures advanced wear leveling; even use of entire flash region		Intelligent algorithm ensures advanced wear leveling; even use of entire flash region
Read Endurance		Unlimited		Unlimited
Wear-leveling Algorithm		Dynamic and static wear-leveling		Dynamic and static wear-leveling
Data Retention		10 years at 25C (77F)		10 years at 25C (77F)
Mean Time Between Failures		1,000,000 hours		1,000,000 hours
Error Correction Code		7-bit ECC		7-bit ECC
Power consumption (idle/active)		0.5/2.0 watts		0.5/2.7 watts
Certifications		RoHS-compliant; CE FCC and MIC certifications		RoHS-compliant; CE FCC and MIC certifications
Support		Access to Imation's industry-leading storage and technical expertise - making the product easy to use, install and configure		Access to Imation's industry-leading storage and technical expertise - making the product easy to use, install and configure
Warranty		3 years		5 years

* ATTO 2.41
** IO Meter 2006.07.27
⁺ Performance may vary by model and system.

Imation Solid State Drives powered by Mtron provide great benefits for select environments, such as superior performance, enhanced lifetime reliability and environmental endurance. Here are some examples of where it makes sense to incorporate solid state drives (SSD) in a data storage environment.

• High End PC's
  An SSD is faster than the fastest hard disk drive (HDD) - booting, loading and opening files almost instantly.

• Harsh Environments
  SSDs are more suitable for harsh environments because they lack moving parts - making them better able to withstand extremes in temperature, vibration or shock.

• Kiosks & Custom Systems
  SSD's emit less heat than an HDD, is more durable -- handling an impact up to 1500G, and has a much higher mean time between failure (MTBF) rating.

• Storage Arrays (RAIDS)
  SSD's drastically reduce the total cost of ownership compared to HDDs and deliver faster boot times, data processing and data storage.
